PBR Panel

Description: For roof and sidewalls. Panels have deep ribs that create an even-shadowed appearance. Area between major ribs is reinforced with minor ribs. One of the most economical wall covering systems available.
Gauge: 29, 26, 24 and 22.
Length: 45' maximum is standard; longer lengths available by special order.
Fasteners: Standard coated; zinc-aluminum cast head; or stainless steel head screw.
Dimensions: 36" coverage x 1-1/4" deep.
Finish: Galvalume Plus® and Commercial-Industrial Series.
Usage: Roof, wall, liner, mansard, and soffit panel applications.

PBR Panel Advantages:

  • 36" coverage.
  • Low freight: manufactured at all plants.
  • Flexible: installation from either end.
  • Economical, cost effective profile.
  • 20-year life warranty on finish, when used with long-life fasteners.
  • Diaphragm capabilities and girt stability in metal building construction.
  • Profile wall lights are available.
  • Can be reverse rolled, with paint finish on the underside for installation as wall panel.

PBA Panel

Description: For sidewalls. Produces a decorative, smooth shadow line for a distinctive architectural effect with semi-concealed fasteners. Ribs are 1-1/8" deep; major corrugations spaced 12" on center. Net panel coverage is 3'-0".
Gauge: 26 and 24.
Lengths: Maximum recommended 45' 0". Longer lengths available by special order.
Fasteners: Various, depending on application.
Dimensions: 36" wide by 1-1/8" deep.
Finish: Galvalume Plus® and Commercial-Industrial Series.
Usage: Wall panel, liner panel, soffit panel, mansard panel face, and back sheet.
Limitation: Installation may be difficult with very thick insulation.

PBA Panel Advantages:

  • Architectural effect: semi-concealed fastener panel.
  • Textured appearance: striations reduce oil canning.
  • Standard Dura-20® silicone polyester color comes with 20-year warranty.
  • Ease of installation and no end laps: single, continuous panel to sill up to 40'-0 panel length.
  • Optional premium paint finish: Royal K-70® with 20-year warranty; ultimate resistance to color change and chalk.
  • Optional embossed texture. Embossed metal reduces glare and potential for oil canning.
  • UL "Class A" fire rating.

PBU Utility Panel

Description: For liners, partitions, soffits. Panel has ribs 6" on centers. Shallower 3/4" deep ribs and relative ease of installation.
Gauge: 29, 26, 24, and 22.
Lengths: Maximum recommended 40' 0". Longer lengths available by special order.
Finish: Galvalume Plus® and Commercial-Industrial Series (29, 24, and 22 Ga. available in Polar White and Galvalume Plus®).
Usage: Wall panel, liner panel, soffit panel, mansard panel face, and back sheet.

PBU Panel Advantages:

  • 20-year warranty on Dura-20®.
  • Reverse rolled profile places color on the reverse side of the panel, yielding a flat profile appearance with fasteners recessed in flutes.
  • UL "Class A" fire rating.
  • Ease of installation and no end laps: single, continuous panel, eave to sill up to 40'-0 panel length.
  • Optional premium paint finish: Royal K-70® with 20-year warranty, ultimate resistance to color change and chalk.
  • Face fastener, yielding diaphragm capabilities and girt stability.
  • Optional embossed texture. Embossed metal reduces glare and potential for oil canning.
  • Optional Perforated condition for ventilation or acoustical applications.

NuWall™ Panel

Description: For new and retrofit applications. Ease of installation and aesthetic appeal. The shadow lines of the NuWall™ panel enhance any structure's appearance. Installation is completely outside; no disruption of workplace.
Gauge: 22, 24, and 26 (Minimum quantity required).
Lengths: Recommended 40'-0" maximum.
Fasteners: Concealed fastening system. Panel is attached to structure with self-drilling fasteners on one side only. No clips are required. Adjoining panel simply snaps into the previous panel, concealing the fasteners from view.
Dimensions: 12" wide, 1" high.
Finish: Galvalume Plus® and Architectural Series.
Usage: In retrofit applications, the NuWall™ panel can be installed over an existing PBR or M panel wall, saving labor and material. Other panel profiles and forms of construction may require the use of sub-girts.

Flat Panels – Artisan Series

Description: For soffits and interior liners. Simplicity is the Artisan Series' best design feature. Uniform dimensions and clean appearance allow the designer to plan modules, eliminate complicated pieces, and follow wall curvatures.
Gauge: 26, 24, and 22 (26 and 22 Ga. may require minimum quantity).
Lengths: Maximum recommended 20'-0" Rules of Thumb for Artisan Panel Lengths:

  • Up to 4'-0" Length: Use L12, L10, or L8.
  • 4'-0" to 10'-0" Length: Use L8 only.

Fasteners: Concealed fastening system Artisan Series panels are attached directly to the substructure using the positive fastening method. The fastener is concealed behind the flush face.
Dimensions: 8", 10", and 12" wide by 1" high.
Finish: Galvalume Plus® and Polar White (Smooth or Embossed Texture with or without stiffener breaks), Commercial-Industrial Series.
Usage: The Artisan panels are used for soffits and interior liners.

Artisan Series Advantages:

  • Factory applied sidelap sealant for watertight connection.
  • The panel sidelap has passed tests for air infiltration and water penetration per ASTM E283 and E331 test procedures.
  • The panels qualify for 1, 1-1/2, and 2 hour UL fire ratings when installed under certain composite construction methods. This provides possible lower insurance costs, and meets code requirements.
  • Perforation available for ventilation or acoustical applications.
  • Rock wall option; an aggregate coating for aesthetic applications.
  • Structural integrity due to panel depth and gauge availability; large spanning conditions are available.
  • Finish warranties available, a 20-year warranty is available for Gavalume Plus® and a 20-year warranty is available for Royal K-70®.

Artisan Series Challenges:

  • Concealed fastener design means no diaphragm action. Installation over thick or reinforced blanket insulation may induce oil canning. Product is designed for application over rigid framing.
  • Product is best sold in the heaviest gauge, embossed and with grooves when possible, as it is susceptible to oil canning.
  • Not recommended for external wall application.

ShadowRib™

Description: ShadowRib™ helps to define metal structures by combining aesthetics, economics, and function. A proven performer and versatile tool for the designer.
Gauge: 24 and 22 (22 Ga. minimum quantity may be required).
Lengths: Maximum recommended 40'-0".
Fasteners: Concealed fastening system. Panels may be secured to the structure from outside the building with the ShadowRib™ concealed clip, or from inside the building with an expansion fastener. Both are positive fastening methods that create secure interlock between panel and structure.
Dimensions: 16" wide by 3" high.
Finish: Galvalume Plus® and Architectural Series.
Usage: For walls, fascias, and equipment screens. Apply the panel over light gauge framing, purlins, girts, structural steel and joists. In many instances, the panel can span floor to ceiling without interior support, making it ready to apply a variety of insulation methods into the 3" cavity.

SSP panels from Insulated Panel Systems (IPS)

Exclusively from Insulated Panel Systems is the SSP roof panel. SSP panels are ideal for temperature-controlled roof systems. The can be snapped together with IPS's patented Versalok™ sidelaps, then mechanically seamed. IPS's EWP Wall Panels, ESP Wall Panels, and IPP Partition Panel system are thermally efficient, affordable, aesthetically pleasing products.

The wall panels are available with our Rockwall™ system. The Rockwall™ process bonds real stone aggregate to steel panels, combining the advantages of steel with the durability and beauty of stone aggregate.

Insulated EWP Wall Panel

Description: Contemporary styling in an easily installed. EWP uses a joint with concealed fasteners. Ribbed profile gives the building a strong vertical accent, ideal for metal building applications. Both exterior and interior metal skins have stucco embossed pre-painted finish. Panel is designed to module on 36" width.
Gauge: 22, 24, and 26 (22 Ga. minimum order required).
Lengths: Max 48'-0".
Fasteners: Concealed with clips at side joints.
Dimensions: Width: 36"; Thickness: 2", 2 1/2", 3", and 4".
Finish: Both faces are stucco embossed, Rockwall™ Stone-Coated, silicone polyester, and fluorocarbon polymer.
Usage: Vertical linear profile allow maximum use of shadows and flat surfaces to create a custom wall effect.
Additional: Load/span tables for wind loads are available upon request.

Insulated EWP Advantages:

  • Excellent insulating properties: foam thickness of 2", 2-1/2", 3", and 4" with R-values from 17.2 to 30.6.
  • Complete Load/Span tables available allowing designer to make proper use of panel span capabilities.
  • Panel joint confirms weather tightness in compliance with specifications. Excellent test results for air leakage and water penetration.
  • Good Surface burning characteristics, complying with model building codes for foam plastics.
  • Concealed fasteners with clips; a contemporary alternative to exposed fasteners.
  • Vertical indented ribs at 6" centers, utilizing maximum use of shadows and flat surfaces for strong vertical accents.

Insulated ESP Wall Panel

Description: Architecturally pleasing and ideal for commercial applications. Low profile exterior structure and offset lap joint with concealed fasteners give ESP panels an attractive appearance for vertical applications. The panel is designed to module on 36" width.
Gauge: 22, 24, and 26 (22 Ga. minimum order required).
Lengths: Max 48'-0".
Fasteners: Concealed with clips at side joints.
Dimensions: Width: 36"; Thickness: 2", 2-1/2", 3", and 4".
Finish: Surfaces are stucco embossed, Rockwall™ Stone-Coated, silicone polyester, and fluorocarbon polymer.
Usage: An economical insulated wall system.
Additional: Load/span tables for wind loads are available upon request.



Insulated ESP Advantages:

  • Excellent insulating properties with foam thickness of 2", 2-1/2", 3", and 4" with R-values from 17.2 to 30.6.
  • Complete Load/Span tables available, allowing designer to make proper use of panel span capabilities.
  • Panel joint confirms weather tightness in compliance with specifications. Excellent test results for air leakage and water penetration.
  • Good Surface burning characteristics, complying with model building codes for foam plastics.
  • Concealed fasteners with clips; a contemporary alternative to exposed fasteners.
  • Lightly striated design gives a flat appearance for most architectural and commercial applications.

Insulated IPP Liner Panel


Description: Flat embossed profile in thicknesses of 2" to 4". IPP utilizes a concealed fastener joint that retains the high thermal properties built into all IPS insulated panels. Easy to maintain finishes; designed to module on 36" centers and has an USDA approved finish as a standard coating.
Gauge: 22, 24, and 26 both faces (22 Ga. minimum order required).
Lengths: Max 48'-0".
Fasteners: Concealed with clips. Concealed fastener installation hardware includes steel clips and screws.
Dimensions: 36" wide by 2", 2-1/2", 3", and 4" thick.
Finish: Both faces are stucco embossed, Rockwall™ Stone-Coated, Dura-20®, and Royal K- 70®.
Usage: Interior partitions and ceilings. Can also be used as an exterior wall panel.
Additional: Butyl side-joint sealant is field installed.



Insulated IPP Advantages:

  • Excellent insulating properties: foam thickness of 2", 2 1/2", 3", and 4" providing R-values from 17.2 to 30.6.
  • Complete Load/Span tables available, allowing designer to make proper use of panel span capabilities.
  • Panel joint confirms weather tightness in compliance with specifications. Excellent test results for air leakage and water penetration.
  • Good surface burning characteristics complying with model building codes for foam plastics.
  • Concealed fasteners with clips; a contemporary alternative to exposed fasteners.
    Symmetrical mesa embossed surfaces on both sides for uniformity in finish and color throughout the building's interior.
  • 48'-0" maximum length which allows for continuous uninterrupted partition walls capable of withstanding most interior design loads (5 psf).
  • Energy efficient, instant interior partition.
  • Offset lap joint retains high thermal properties.

Insulated Rockwall™ Stone-Coated TecFoam Walls

Description: For wall applications only. All insulated wall panels are available with the Rockwall™ Finish system. Rockwall™ gives you durable steel wall panel construction with the beauty of stone aggregate. The Rockwall™ process bonds real stone aggregate to steel panels with a super adhesive system. A clear sealer gives the finished panel a crisp glazed appearance.
Gauges: 24 and 26.
Lengths: Max 20' Fasteners: Concealed with clips.
Dimensions: Width: 36"; Thickness: 2"- 4".
Finishes: Sand Rock, and Granite Rock.
Usage: The Rockwall™ finish is available on all panel profiles:

  • RWP Roof/Wall Panel
  • EWP Wall Panel
  • ESP Wall Panel
  • IPP Partition Panel

IPS Rockwall™ Advantages:

  • Excellent insulating properties: foam thickness of 2", 2-1/2", 3", and 4" withR-values from 17.2 to 30.6.
  • Complete Load/Span tables available, allowing designer to make proper use of panel span capabilities.
  • Panel joint confirms weather tightness in compliance with specifications. Excellent test results for air leakage and water penetration.
  • Good surface burning characteristics, complying with model building codes for foam plastics.
  • Concealed fasteners with clips; a contemporary alternative to exposed fasteners.
